TES-1339

Light Meter Pro.

Product Features
  • Dual Display, 4-digit LCD reading.
  • Spectral Sensitivity close to CIE photopic Curve.
  • Measuring Levels Ranging 0.01 to 999900 Lux,
    0.01 to 92920 fc, Autoranging 5 step.
  • Accurate and Instant response.
  • Integral illuminance measurement.
  • Luminous intensity measurement.
  • Data Hold function.
  • Data memory and read function.
  • Reference value setting for relative or percentage
    deviation measurement.
  • Ripple measurement for STRAY + LIGHT function.
  • Time-hold function.
  • Point - average function.
  • Comparator function.
  • Auto power off function.
  • CNS 5119 ClassⅡ.
Light Meter Pro.



Display

Dual display 4 digit LCD read out.

Measuring Range

99.99, 999.9, 9999, 99990, 999900 Lux
 9.292, 92.92, 929.2, 9292, 92920 fc
Auto rangeing (5 step)     (1 fc = 10.76 Lux)

Overrange Display

OL is displayed

Resolution

0.01 Lux, 0.001 fc

Accuracy

±3% rdg ±5dgt (Calibrated to standard
 incandescent lamp, 2856
Κ)

CIE photopic f ’1

6%

Temperature Characteristics

±0.1%/

Measuring Rate

Approximately 5 time/sec

Photosensor

Silicon photodiodes

Data Memory Capacity

50 sets. (Direct reading from LCD display)

Operating / Storage Conditions

0 ~ 40 <80% RH / -10 ~ 50 <70%RH

Power Source

6 pcs AAA size Battery

Battery Life (typical)

100 hours

Photosensor Lead Length

150 cm (approx.)

Photosensor Dimensions

92(L) ×60(W) ×29(H)mm

Dimension

150(L) ×72(W) ×35(H)mm

Weight

320g

Accessories

Carrying case, Instruction manual, Battery
