Hot-Wire Anemometer

Hot-Wire Anemometer

TES-1340

Hot-Wire Anemometer

Product Features

Fast response probe.
Air flow volume.
Instant / Avg / V max flow measurement.
Velocity m / s, f t / min, knots, km / hr, mph, Bft.
Data hold & Maximum / Minimum / Average function.
Manual data memory and read function (5 x 99 sets).
Auto data memory and read function (5 x 99 sets).
Backlight LCD display
LCD triple display.
Auto power off function ON / OFF Time setting.
Backlight function ON / OFF Time setting.
Snake telescoping probe.
Simple and safe to use.

Specification
Application
Download

	Measuring Range	Resolution	Accuracy
Air Flow	0 to 30.0 m/s	0.01 m/s	±3% of reading ±1%FS
	0.2 to 110 km/hr	0.1 km/hr
	10 to 6000 ft/min	1 ft/min
	0.1 to 59 knots	0.01 knots
	0.12 to 68 mile/hr	0.01 mile/hr
Air Flow Volume	0 to 999900 m³/min	0.001 m³/min
Air Flow Volume	0 to 999900 ft³/min	0.001 ft³/min

Response time	< 2 second
Manual Memory Capacity	5 x 99 sets. (Direct reading from LCD display)
Auto Memory Capacity	5 x 99 sets. (Direct reading from LCD display)
Operating Conditions	0°C ~ 50°C (32°F ~ 122°F), ≤ 80% R.H.
Power Source	6 pcs size AAA Battery
Battery Life	Approx. 10 hours
Size	150(L) ×72(W) ×35(H)mm
Weight	Approx. 235g
Accessories	Instruction manual, Battery, Carrying case
