Light Meter
TES-1339R
Data Logger Light Meter Pro.
Product Features
- Spectral correction factor function (include LED)
- User calibration function (CAL)
- Dual Display, 4-digit LCD reading.
- Spectral Sensitivity close to CIE photopic Curve.
- Measuring Levels Ranging 0.01 to 999900 Lux,0.001 to 92927 fc, Autoranging 5 step.
- Accurate and Instant response.
- Integral illuminance measurement.
- Luminous intensity measurement.
- Data Hold function.
- Data memory and read function.
- Data logger function.
- Reference value setting for relative or percentage deviation measurement.
- Ripple measurement for STRAY + LIGHT function.
- Time-hold function.
- Point - average function.
- Comparator function.
- Auto power off function.
- RS232 Interface.
|
Display
|
Dual display 4 digit LCD read out.
|
|
Measuring Range
|
99.99, 999.9, 9999, 99990, 999900 Lux
9.292, 92.92, 929.2, 9292, 92920 fc Auto rangeing (5 step) (1 fc = 10.76 Lux) |
|
Overrange Display
|
OL is displayed
|
|
Resolution
|
0.01 Lux, 0.001 fc
|
|
Accuracy
|
±3% rdg ±5dgt (Calibrated to standard
incandescent lamp, 2856 Κ) |
|
CIE photopic f ’1
|
≦6%
|
|
Temperature Characteristics
|
±0.1%/℃
|
|
Measuring Rate
|
Approximately 5 time/sec
|
|
Photosensor
|
Silicon photodiodes
|
|
Data Memory Capacity
|
99 sets. (Direct reading from LCD display)
|
|
Data Logger Capacity
|
40000 sets.
|
|
Operating / Storage Conditions
|
0℃ ~ 40℃ <80% RH
-10℃ ~ 50℃ <70%RH |
|
Power Source
|
6 pcs AAA size Battery
|
|
Battery Life (typical)
|
100 hours
|
|
Photosensor Lead Length
|
150 cm (approx.)
|
|
Photosensor Dimensions
|
92(L) × 60(W) × 29(H)mm
|
|
Dimension
|
150(L) × 72(W) × 35(H)mm
|
|
Weight
|
320g
|
|
Accessories
|
Carrying case, Instruction manual, Battery,
CD software, RS232 cable. |
