Light Meter
Light Meter Pro.
- Spectral correction factor function (include LED)
- User calibration function (CAL)
- Dual Display, 4-digit LCD reading.
- Spectral Sensitivity close to CIE photopic Curve.
- Measuring Levels Ranging 0.01 to 999900 Lux, 0.01 to 92920 fc, Autoranging 5 step.
- Accurate and Instant response.
- Integral illuminance measurement.
- Luminous intensity measurement.
- Data Hold function.
- Data memory and read function.
- Reference value setting for relative or percentage deviation measurement.
- Ripple measurement for STRAY + LIGHT function.
- Time-hold function.
- Point - average function.
- Comparator function.
- Auto power off function.
Display |
Dual display 4 digit LCD read out. |
Measuring Range |
99.99, 999.9, 9999, 99990, 999900 Lux |
Overrange Display |
OL is displayed |
Resolution |
0.01 Lux, 0.001 fc |
Accuracy |
±3% rdg ±5dgt (Calibrated to standard |
CIE photopic f ’1 |
≦6% |
Temperature Characteristics |
±0.1%/°C |
Measuring Rate |
Approximately 5 time/sec |
Photosensor |
Silicon photodiodes |
Data Memory Capacity |
50 sets. (Direct reading from LCD display) |
Operating / Storage Conditions |
0°C~ 40°C<80% RH / -10°C ~ 50°C <70%RH |
Power Source |
6 pcs AAA size Battery |
Battery Life (typical) |
100 hours |
Photosensor Lead Length |
150 cm (approx.) |
Photosensor Dimensions |
92(L) ×60(W) ×29(H)mm |
Dimension |
150(L) ×72(W) ×35(H)mm |
Weight |
320g |
Accessories |
Carrying case, Instruction manual, Battery |
