TES Electrical Electronic Corp.

Display

3 3/4 digit LCD with bargraph indication.

Measuring Range

40.00Lux、400.0Lux、4000Lux、40.00KLux、

400.0KLux、40.00fc、400.0fc、4000fc、40.00Kfc
(1 fc = 10.76 Lux)

Overrange Display

“OL” is displayed

Resolution

0.01 Lux, 0.01 fc

Accuracy

±3%rdg ± 0.5% f.s.
(±4%rdg±10 dgts as > 10,000 lux range).

(calibrated to standard incandescent lamp at color temperature 2856K).

CIE photopic

f ’₁ ≦ 6%

Cosine Response

f ’₂ ≦ 2%

Temperature Characteristics

±0.1% 1°c

Measuring Rate

Digits : 1.3/sec

Analog : 13.3/sec

Photosensor

Silicon photodiodes

Operating / Storage Conditions

0°c~ 40°c <80% RH
 -10°c ~ 60°c <70%RH

Power Source

6 pcs AAA size Battery

Battery Life (typical)

400 hours

Photosensor Lead Length

150 cm (approx.)

Photosensor Dimensions

920(L) ×60(W) ×29(H)mm

Dimension

150(L) ×72(W) ×35(H)mm

Weight

320g

Accessories

Carrying case, Instruction manual, Battery
